Sonara 4:1


The Panalux Sonara 4:1 variable-white LED head incorporates the same innovative LED light engine common to the Panalux Sonara family, in a form factor that serves as an ideal replacement for traditional fluorescent heads. All Panalux Sonara fixtures deliver soft, wraparound, color-accurate white light with a CCT range of 1,600-20,000K and a built-in library of select LEE Filters gel emulations. Other shared features across the Panalux Sonara family include 0-100% dimming, flicker-free performance tested to 10,000 fps, full connectivity options including native LumenRadio CRMX, and a range of control modes that can be easily navigated via detachable controller and intuitive user interface.







Product Details

Manufacturer Panalux
Model Sonara 4:1
Dimensions (mm)(in) 1248 x 348 x 134
Variant 4:1
Power Draw (W) 350
Lux @ 3M (3200K) 885 (Spot)
Lux @ 3M (5600K) 1168 (Spot)
TLCI 95.5
CRI 96.3
SSI 82
Built in Effects No
Connector Type 1 x Powercon True1 In, Head
CCT Range 1600-20000K
Light Aperture 1200 x 300
Beam Angle Max (°) 120
Battery Operated No
High Speed Capability Yes
Protection Rating IP20
Mounting 28mm Spigot / M12 fixings
Weight (kg)(lbs) 13.9030.6

Ultra-soft light: With a wide aperture and 120-degree beam angle, Panalux Sonara produces a powerful, diffuse output that wraps around any subject.

Remarkably precise white: Precise white color-temperature light allows for accurate, natural skin-tone rendering. Panalux Sonara can also be tuned across a wide array of nuanced pastel hues and selected LEE Filters lighting gels, further expanding your creative possibilities.

Comprehensive control: The removable controller allows flexibility and versatility on set, with White, HSI, Gel, Primary/Clone, and x y Coordinate modes.

Enhanced connectivity: Incorporating unrivaled connectivity options with native LumenRadio CRMX, ArtNet, and Primary/Clone functionality, Panalux Sonara allows you to connect however your job demands.

Created by and only available from Panalux.

Panalux Sonara 4:1 Spec Sheet

Overview of the key features and specs of the Panalux Sonara 4:1 variable-white LED soft light.

Download PDF

Panalux Sonara Family Manual

User manual detailing the features and operation of the Panalux Sonara range of variable-white LED soft lights.

Download PDF
